|Size & Pressure Rating & Standard|
|Pressure Rating||PN10, PN16, CL150, JIS 5K, JIS 10K|
|Face to Face STD||API609, BS5155, DIN3202, ISO5752|
|Connection STD||PN6, PN10, PN16, PN25, 150LB, JIS5K, 10K, 16K, GOST33259|
|Upper Flange STD||ISO 5211|
|Body||Cast Iron(GG25), Ductile Iron(GGG40/50), Carbon Steel(WCB A216), Stainless Steel(SS304/SS316/SS304L/SS316L) , Duplex Stainless Steel(2507/1.4529), Bronze, Aluminium Alloy.|
|Disc||DI+Ni, Carbon Steel(WCB A216), Stainless Steel(SS304/SS316/SS304L/SS316L) , Duplex Stainless Steel(2507/1.4529), Bronze, DI/WCB/SS coated with Epoxy Painting/Nylon/EPDM/NBR/PTFE/PFA|
|Stem/Shaft||SS416, SS431, SS304, SS316, Duplex Stainless Steel, Monel|
|Seat||NBR, EPDM/REPDM, PTFE/RPTFE, Viton, Neoprene, Hypalon, Silicon, PFA|
|O Ring||NBR, EPDM, FKM|
|Actuator||Hand Lever, Gear Box, Electric Actuator, Pneumatic Actuator|
Pipelines, especially those used for severely corrosive media such as hydrofluoric acid, phosphoric acid, chlorine, strong alkalis, aqua regia and
Other highly corrosive media.
Small size, easy to install.
4-level load elastic seal absolutely guarantees zero leakage inside and outside the valve.
This product is used for the water supply and drainage system in tap water, sewage, building, chemical etc. industries, usually used as an open-close equipment.
Butterfly valves are like ball valves but have more advantages. They are open and close very quickly when actuated pneumatically. The disc is lighter than a ball, and the valves require less structural support than a ball valve of comparable diameter. Butterfly valves are very precise, which makes them advantageous in industrial applications. They are quite reliable and require very little maintenance.
It can be used for transmitting mud, fewer liquids are stored at apertures of pipe.
Long service life. Standing the test of tens of thousands of opening/closing operations.
Butterfly valves have excellent regulation performance.
Body Test: The valve body test use 1.5 times pressure than standard pressure. The test should be done after installation, the valve disc is half close, called body pressure test. The valve seat uses 1.1 times pressure than standard pressure.
Special Test: According to customer’s requirement, we can do any test you need.
Suitable Media: Wafer and other neutral medium, working temperature from -20 to 120℃, the application of the valve can be municipal construction, wafer conservancy project, water treatment etc.
